Satori: Enlightened library to convert HTML and CSS to SVG.

Note

> To use Satori in your project to generate PNG images like Open Graph images and social cards, check out our announcement and Vercel’s Open Graph Image Generation docs →

> To use it in Next.js, take a look at the Open Graph Image Generation examples →

Overview

Satori supports the JSX syntax, which makes it very straightforward to use. Here’s an overview of the basic usage:

// api.jsx
import satori from 'satori'
const svg = await satori(

hello, world,
  {
    width: 600,
    height: 400,
    fonts: [
      {
        name: 'Roboto',
        // Use fs (Node.js only) or fetch to read the font as Buffer/ArrayBuffer and provide data here.
        data: robotoArrayBuffer,
        weight: 400,
        style: 'normal',
      },
    ],
  },
)

Satori will render the element into a 600×400 SVG, and return the SVG string:

''

Under the hood, it handles layout calculation, font, typography and more, to generate a SVG that matches the exact same HTML and CSS in a browser.

Documentation

JSX

Satori only accepts JSX elements that are pure and stateless. You can use a subset of HTML elements (see section below), or custom React components, but React APIs such as useState, useEffect, dangerouslySetInnerHTML are not supported.

Experimental: builtin JSX support

Satori has an experimental JSX runtime that you can use without having to install React. You can enable it on a per-file basis with @jsxImportSource pragmas. In the future, it will autocomplete only the subset of HTML elements and CSS properties that Satori supports for better type-safety.

/** @jsxRuntime automatic */
/** @jsxImportSource satori/jsx */
import satori from 'satori';
import { FC, JSXNode } from 'satori/jsx';
const MyComponent: FC<{ children: JSXNode }> = ({ children }) => (

{children}
)
const svg = await satori(
  hello, world,
  options,
)

Use without JSX

If you don't have JSX transpiler enabled, you can simply pass React-elements-like objects that have type, props.children and props.style (and other properties too) directly:

await satori(
  {
    type: 'div',
    props: {
      children: 'hello, world',
      style: { color: 'black' },
    },
  },
  options
)

HTML Elements

Satori supports a limited subset of HTML and CSS features, due to its special use cases. In general, only these static and visible elements and properties that are implemented.

For example, the ` HTML element, the cursor CSS property are not in consideration. And you can't use tags or external resources via or `.

Also, Satori does not guarantee that the SVG will 100% match the browser-rendered HTML output since Satori implements its own layout engine based on the SVG 1.1 spec.

You can find the list of supported HTML elements and their preset styles here.

Images

You can use to embed images. However, width, and height attributes are recommended to set:

await satori(
  ,
  options
)

When using background-image, the image will be stretched to fit the element by default if you don't specify the size.

If you want to render the generated SVG to another image format such as PNG, it would be better to use base64 encoded image data (or buffer) directly as props.src so no extra I/O is needed in Satori:

await satori(
  ,
  // Or src={arrayBuffer}, src={buffer}
  options
)

CSS

Satori uses the same Flexbox layout engine as React Native, and it’s not a complete CSS implementation. However, it supports a subset of the spec that covers most common CSS features:

Property	Property Expanded	Supported Values
CSS Variables	Supported, including `--var-name` declaration and `var(--var-name)` usage with fallback values	Example
`display`	`flex`, `block`, `contents`, `none`, `-webkit-box`, default to `flex`. Use `flex`, `contents`, or `none` for `div` elements with multiple child nodes.
`position`	`relative`, `static` and `absolute`, default to `relative`
`color`	Supported
`margin`
`marginTop`	Supported
`marginRight`	Supported
`marginBottom`	Supported
`marginLeft`	Supported
Position
`top`	Supported
`right`	Supported
`bottom`	Supported
`left`	Supported
Size
`width`	Supported
`height`	Supported
Min & max size
`minWidth`	Supported except for `min-content`, `max-content` and `fit-content`
`minHeight`	Supported except for `min-content`, `max-content` and `fit-content`
`maxWidth`	Supported except for `min-content`, `max-content` and `fit-content`
`maxHeight`	Supported except for `min-content`, `max-content` and `fit-content`
`border`
Width (`borderWidth`, `borderTopWidth`, ...)	Supported
Style (`borderStyle`, `borderTopStyle`, ...)	`solid` and `dashed`, default to `solid`
Color (`borderColor`, `borderTopColor`, ...)	Supported
Shorthand (`border`, `borderTop`, ...)	Supported, i.e. `1px solid gray`
`borderRadius`
`borderTopLeftRadius`	Supported
`borderTopRightRadius`	Supported
`borderBottomLeftRadius`	Supported
`borderBottomRightRadius`	Supported
Shorthand	Supported, i.e. `5px`, `50% / 5px`
`cornerShape`
Values	`round`, `squircle`, `square`, `bevel`, `scoop`, `notch`, and `superellipse()`
Corner longhands (`cornerTopLeftShape`, `cornerTopRightShape`, ...)	Supported
Side shorthands (`cornerTopShape`, `cornerRightShape`, ...)	Supported. Corner shapes apply when the corresponding `borderRadius` is nonzero.
Flex
`flexDirection`	`column`, `row`, `row-reverse`, `column-reverse`, default to `row`
`flexWrap`	`wrap`, `nowrap`, `wrap-reverse`, default to `nowrap`
`flexGrow`	Supported
`flexShrink`	Supported
`flexBasis`	Supported except for `auto`
`alignItems`	`stretch`, `center`, `flex-start`, `flex-end`, `baseline`, `normal`, default to `stretch`
`alignContent`	Supported
`alignSelf`	Supported
`justifyContent`	Supported
`gap`	Supported
Font
`fontFamily`	Supported
`fontSize`	Supported
`fontWeight`	Supported
`fontStyle`	Supported
`fontFeatureSettings`	Supported via HarfBuzz text shaping. Enables OpenType features like ligatures, small caps, stylistic sets, etc.
Text
`tabSize`	Supported
`textAlign`	`start`, `end`, `left`, `right`, `center`, `justify`, default to `start`
`textIndent`	Supported, including negative values (hanging indent)
`textTransform`	`none`, `lowercase`, `uppercase`, `capitalize`, defaults to `none`
`textOverflow`	`clip`, `ellipsis`, defaults to `clip`
`textDecoration`	Support line types `underline` and `line-through`, and styles `dotted`, `dashed`, `double`, `solid`	Example
`textShadow`	Supported
`lineHeight`	Supported
`letterSpacing`	Supported
`whiteSpace`	`normal`, `pre`, `pre-wrap`, `pre-line`, `nowrap`, defaults to `normal`
`wordBreak`	`normal`, `break-all`, `break-word`, `keep-all`, defaults to `normal`
`textWrap`	`wrap`, `balance`, defaults to `wrap`
Background
`backgroundColor`	Supported, single value
`backgroundImage`	`linear-gradient`, `repeating-linear-gradient`, `radial-gradient`, `repeating-radial-gradient`, `url`, single value
`backgroundPosition`	Support single value
`backgroundSize`	Support `cover`, `contain`, `auto`, and two-value sizes i.e. `10px 20%`	Example
`backgroundClip`	`border-box`, `text`
`backgroundRepeat`	`repeat`, `repeat-x`, `repeat-y`, `no-repeat`, defaults to `repeat`
`transform`
Translate (`translate`, `translateX`, `translateY`)	Supported
Rotate	Supported
Scale (`scale`, `scaleX`, `scaleY`)	Supported
Skew (`skew`, `skewX`, `skewY`)	Supported
`transformOrigin`	Support one-value and two-value syntax (both relative and absolute values)
`objectFit`	Supported	Example
`objectPosition`	Supports keywords (`top`, `bottom`, `left`, `right`, `center`), percentages (e.g., `25% 75%`), lengths (e.g., `10px 20px`), and mixed values (e.g., `left 20%`). Defaults to `center` (`50% 50%`).	Example
`opacity`	Supported
`boxSizing`	Supported
`boxShadow`	Supported
`overflow`	`visible` and `hidden`, default to `visible`
`filter`	Supported
`backdropFilter`	Supports chained `blur()`, `brightness()`, `contrast()`, `drop-shadow()`, `grayscale()`, `hue-rotate()`, `invert()`, `opacity()`, `saturate()`, and `sepia()`
`clipPath`	Supports `circle()`, `ellipse()`, `inset()`, `polygon()`, `path()`, and `shape()`. `shape()` supports `move`, `line`, `hline`, `vline`, `curve`, `smooth`, `arc`, and `close` commands.	Example
`lineClamp`	Supported when the text element uses `display: block`. For WebKit-style clamping, use `display: -webkit-box` with `WebkitLineClamp`.	Example
Mask
`maskImage`	`linear-gradient(...)`, `radial-gradient(...)`, `url(...)`	Example
`maskPosition`	Supported	Example
`maskSize`	Support two-value size i.e. `10px 20%`	Example
`maskRepeat`	`repeat`, `repeat-x`, `repeat-y`, `no-repeat`, defaults to `repeat`	<a href="https://og-playground.vercel.app/?share=nVbpjqNIEn6VkqXVzMg1AhtjQ-3MStwGA-Ywl9U_hssJ5jSHAbf63TdxdfXUzh4_FhllHF8cGZkm4usirKJ48bb4LUrvX8qXl7ab8vj3r19n-uUliVOQdG8vP61Q9G8_vb4LhzTqkr_IorStc3-C0ksejx_SmWbTJg67tCqhLqzyvig_tH6eglLs4qKdVXHZxc2H6tq3XXqZmAoKyzn-v6ovUG6mj_jtBVt_Ejnfs92i6Hdp4IcZaKq-jKCPvsl_jvzOf0sLH8RIXYK_B34bbzevqU0fjQE9CKCi4KOaVsJZAFK0PvMaQ3lwYbPiSNqzgHJV00BFqmk34XaGiEbucHlxslDqMNtRAJpyJkUpM0NTFAcXzqco6ztPUSbggs-8BTgY_AMvwl9UU9Qz_lPvPP0-WaiEz6zinkKoPwLIs9_lkGcATGEO-o6jTUANn3iKeJJ2F-6CJ58PJp8_ICFzA7QeFZqSbqHwBOW1zSeow62UY6HeAxNPzgKZnk18E7jfU2LHzbFMulBY5ZHAgVhYtUGpbGMWTT3HuHuFtZ35wLFRzyRScQ-2EDNEQkuKeaJaDM0GmJSLrNcrzGYQr5uDyFBA20vZ-VqbBuf98BkWRqGZUhXtjeGYEvcIizC5DB9yQU7niRiPpwyXH9QkP8RJdqF9unrEDo56Luig_fXD9yf_3NlVr2GRw3zye5DS01nwtp4j3SNXJ8VU_IH_eD9ygfjifEVTf2-gIVvd5TUO8-CzYC3l8rNWJOo750J-cHBfRKqB6rMf4t2-1mDsPCiN5Bn_uhk15t3umJGT79h9JPCQJ_tP9oSM_YfcP-rGwFrAPViZIUAbiH2v97P-p81BsHcJDc-ZWvGSwfHWkRZUm-8UDuWsMsJM7ITXvl8YYxpVaW More Image Trending projects 1 AUTOMATIC1111 / stable-diffusion-webui Python★ 164,942⑂ 0 → 2 Comfy-Org / ComfyUI Python★ 133,239⑂ 0 → 3 opencv / opencv C++★ 90,840⑂ 0 → 4 Developer-Y / cs-video-courses ★ 83,501⑂ 0 → 5 d2l-ai / d2l-zh Python★ 80,681⑂ 0 → 6 unslothai / unsloth Python★ 76,181⑂ 0 → Git Homed · data from GitHub Trending and GitHub topic pages · updated daily · about sitemap · robots
