HakiOS

English · 中文 · Українська

HakiOS runs the open-source XNU kernel (xnu-8796.121.2) with my own boot loader and my own drivers on an Android phone with a Qualcomm SoC, and boots the stock iOS 16.5 user space on top of it: launchd, backboardd, SpringBoard, the apps. The same thing runs in QEMU (virt, aarch64) on a Linux PC.

Nothing is flashed. The loader goes into RAM through fastboot boot, the system lives in RAM for the length of a session, and a reboot brings the phone back to its own Android. This is a research bench, not a ROM.

The first phone is the POCO X5 Pro 5G (redwood, Snapdragon 778G). The kernel knows nothing about it in advance: every address, interrupt, power rail and firmware comes from the phone's own device tree and its own Android, so a port to another Qualcomm phone is a new directory under devices/, not a rewrite.

What is in the repository

Only my code and my data:

• the kernel: a patch to Apple's open-source XNU (xnu/hakios.patch, APSL 2.0) and my driver

files (xnu/files/), laid over a fresh clone by xnu/apply.sh;

• the boot loader (xnuloader/), my programs and libraries (userland/src/), tools (tools/),

build and run scripts;

• prebuilt/: the kernel, loader and libraries built from this repository;
• devices/poco-x5-pro/: what one phone needs (its UEFI port, device tree, firmware script).

Not in the repository, never:

• any file of iOS: no binary, image, cache, font, picture or screenshot. You build the system

image on your machine from the iOS 16.5 IPSW, which sysimage/fetch.sh downloads from Apple's public servers for you, without decrypting or circumventing anything;

• the phone's firmware (GPU, Wi-Fi, audio DSP, modem, haptics, cameras): it is the vendor's and

is pulled from your own phone into fw-*/, which git ignores;

• keys, certificates, activation, or anything that would make the phone pass as an iPhone to

Apple's services. Signing in to an Apple account is impossible here and not a goal.

Status

| Works | Not yet | |---|---| | Lock screen, home screen, Control Center, gestures, the stock apps | Cellular: the modem boots, sees the network, the SIM is bound, the IPA data path and en1 are in place; registration, the data session and the status bar bars are in progress (docs/cellular.md) | | Touch screen, multitouch, power and volume buttons | Bluetooth | | All 8 CPU cores, the big core at 2.4 GHz | Charging under this kernel | | GPU rendering on Adreno (gpu=1, OpenGL ES through Mesa) | Metal (there is a shader compiler, no Metal) | | Speakers and microphone (adsp=1 sound=4 mic=4) | Apple account: no Secure Enclave | | Battery level in the UI (through the audio DSP, adsp=1) | | | Vibration (haptic=5) | | | Wi-Fi: radio, driver, network connection (wifi=1) | | | Cameras in Camera.app (cam=5) | | | /private/var kept across reboots (var_store=1 ufs_write=1) | | | Sileo, Procursus packages, SSH into the phone | |

Quick start in QEMU

Linux x86-64, about 12 GB of disk, 7-Zip 23 or newer, lz4, qemu-system-aarch64, edk2-aarch64.

git clone https://github.com/oosexgang/hakios-os.git hakios
cd hakios
sysimage/fetch.sh             # the iOS 16.5 IPSW from Apple's servers, the needed parts unpacked (7.4 GB)
REST=1 userland/build.sh      # the APFS images: userland/root.apfs and userland/system.apfs
mkdir -p logs
qemu/run-ios.sh 1200 -display gtk > logs/qemu.log     # a 20-minute session

The lock screen appears after two or three minutes. The mouse with the button held is a finger; H is Home, L is the power button, ↑/↓ are volume.

On the phone

A phone with a port (devices/poco-x5-pro/, POCO X5 Pro 5G), its boot loader unlocked, adb and fastboot on the PC, the images from the previous section, and the phone's own firmware:

devices/poco-x5-pro/pull-firmware.sh    # GPU, Wi-Fi, audio/battery, haptics, modem, cameras -> fw-*/
./xl enter                          # Android -> fastboot -> our loader in RAM
./xl ramdisk userland/system.apfs   # the system image into the phone's RAM (~80 s), once per loader session
XL_SB_DELAY=8 XL_SECS=600 \
XL_CMDLINE="bootcpu=7 cpus=8 cpufreq=1 ufs=2 touchscreen=1 gpu=1 adsp=1 sound=4 wifi=1 haptic=5 modem=1" \
./xl run                            # a 10-minute session, the log goes to logs/
./xl reboot                         # back to Android

tools/modem-cycle.sh "ARGS" SECS does all of that in one command and returns the phone to Android.

The main kernel arguments (the full list is in docs/ru/notes.md):

| Argument | What it does | |---|---| | cpus=8 bootcpu=7 cpufreq=1 | all CPU cores and their clocks | | touchscreen=1 | the touch screen | | gpu=1 | rendering on Adreno (an image built with GL=1, firmware in fw-gpu/) | | adsp=1 sound=4 mic=4 | the audio DSP: speakers, microphone; battery and charging come with it | | haptic=5 | the vibration motor | | wifi=1 | Wi-Fi (the network from fw-wifi/network) | | cam=5 | the cameras | | modem=1 | the modem beside the system: its firmware, file systems, IPA, SIM, NAS | | modem_step=N | the modem step by step, for debugging (docs/cellular.md) | | var_store=1 ufs_write=1 | keep /private/var across reboots |

Building from source

The kernel (Linux: theos with its cctools and iPhoneOS16.5.sdk; macOS: Xcode or cctools, the SDK is fetched for you):

xnu/apply.sh             # XNU sources from Apple's GitHub + my changes -> xnu-src/
xnu-deps/setup.sh        # dependencies, tools and the SDK
./xnu-build.sh -j8 -k    # -> xnu-src/.../BUILD/obj/DEVELOPMENT_ARM64_BCM2837/mach.development.bcm2837

The loader: xnuloader/build.sh (clang + lld-link, an EFI application without EDK2). The header xnuloader/identity.h, the properties by which iOS tells which iPhone it is, is not kept in the repository: xnuloader/mkidentity.sh makes it at build time from the device tree in your own IPSW (one 34 KB file; LZFSE is decoded by lzfse, macOS's compression_tool or the Python lzfse module, or the open lzfse library gets built). User space and the images: REST=1 userland/build.sh (MODEM=1 SYSTEM=1 put the modem's firmware into the system image). Details: xnu/README.md, docs/ru/notes.md.

Layout

| Directory | Contents | |---|---| | xnu/ | the kernel patch and files; apply.sh, export.sh; a README about the kernel | | xnu/files/bsd/dev/hakios.*.c | my drivers: display, touch, UFS, GPU, Wi-Fi, audio, modem (hakios.mpss.c), its packets (hakios.ipa.c, hakios.cell.c), SIM/NAS, haptics, cameras | | xnuloader/ | the boot loader (a UEFI application) | | userland/ | my programs and libraries (src/), the image build, launchd jobs | | sysimage/ | scripts that fetch and unpack the OS files from the IPSW (none of the files themselves) | | devices/poco-x5-pro/ | one phone: its UEFI port, device tree, prebuilt UEFI images, firmware script, tools | | tools/ | APFS, firmware, QMI tests, run scripts | | qemu/ | running in QEMU | | docs/ | notes.md: the detailed notes (Russian); cellular.md: cellular; air.md, metal.md: the GPU | | prebuilt/ | the built kernel, loader and libraries |

Devices

The kernel, loader and user space are shared. Everything about one phone lives in devices//: its UEFI, device tree, firmware list and tools. Today there is one, devices/poco-x5-pro/, and its README is the map of what a port to another Qualcomm phone must bring. The phone's drivers are the files xnu/files/bsd/dev/hakios.*.c; the head of each says where its numbers came from.

Cellular

The modem (the Hexagon MPSS) is brought up from XNU: firmware through TrustZone, shared memory, SMP2P, GLINK, QRTR, QMI; its file systems are served from the UFS (read-only, writes stay in kernel memory), TFTP and the service registry are mine. The IPA packet engine runs with its firmware, clock and SMMU context, and the handshake with the modem goes through. The SIM is bound to the subscription and NAS reads the signal. The current state and the whole story are in docs/cellular.md.

Independent, and Apple-free at the core

HakiOS is an independent research project. It is not affiliated with or endorsed by Apple; "iOS", "iPhone", "XNU" and "Apple" are named only to describe what the code works with. The core kernel, the boot loader and the open tools build and run with nothing of Apple's:

make qemu-open      # the open kernel + a placeholder loader + a tiny raw-syscall user space, in QEMU

No IPSW, no iOS user space, no firmware. Booting the stock iOS user space (make qemu, make phone) is an optional path that needs the IPSW and the phone's firmware, which you supply from your own device.

Licenses and the legal side

My code is under the license of the files it changes: the XNU patch under the Apple Public Source License 2.0 (Apple publishes XNU under it; the terms are met: changes are published as source, notices are kept), the rest as the file headers say. iOS, its images, Apple's trademarks and the phone's firmware belong to their owners, are not in this repository and are not distributed by me; everyone takes them from their own phone and their own IPSW. "iOS", "iPhone" and "Apple" are named only to describe what the code works with. If you believe a file here infringes anyone's rights, open an issue and I will remove it.

The detail is in separate files: LEGAL.md (what is and is not distributed, and the limits of these statements), COMPLIANCE.md (how the APSL 2.0 and other terms are met, and the items still to verify), THIRD_PARTY_LICENSES.md (every third-party component with origin and license), and NOTICE (the short canonical list). None of this is legal advice.
