Pascal Editor

An open-source, local-first 3D building editor built with React Three Fiber and WebGPU. Run it in the browser or from the CLI, and connect AI agents through MCP.

https://github.com/user-attachments/assets/8b50e7cf-cebe-4579-9cf3-8786b35f7b6b

Run the Editor Locally

Node.js 22.13 or newer can create a persistent local Pascal installation without cloning this repository:

npx @pascal-app/cli editor

The CLI starts the editor and an authenticated MCP service in the background, selects collision-free loopback ports, and keeps projects in ~/.pascal/data/pascal.db. The npm package holds the CLI and that MCP service; the web editor runtime is downloaded once per version on the first command that starts the editor and verified against a digest published inside the package. Configure an agent to launch pascal mcp connect, which needs neither the editor process nor that download. Install the pascal command with npm install --global @pascal-app/cli. See Run Pascal locally for pnpm/Bun commands, project management, MCP setup, updates, storage paths, and troubleshooting.

Use one active agent client per local CLI service. The standalone local HTTP runtime shares active scene state between clients; use separate PASCAL_HOME directories and service processes when independent concurrent work is required.

Agent skills

Install Pascal's public agent workflows from this repository with skills.sh:

npx skills add pascalorg/editor \
  --skill pascal-3d \
  --skill furniture-fit

Claude Code users can install the same canonical skill source as a plugin:

/plugin marketplace add pascalorg/editor
/plugin install pascal-agent-skills@pascal

The Claude plugin also supplies the local pascal mcp connect server. Install and start the Pascal CLI first, and keep pascal on the PATH used to launch Claude Code. This local connector needs no Pascal account or API key and does not upload projects automatically. Its plugin root is this repository's skills/ directory, so an install copies only the skill bundles and their plugin metadata rather than the repository.

The plugin bundles two servers: the local pascal connector above and a hosted pascal-hosted server for https://editor.pascal.app/api/mcp, which prompts for an optional Pascal API key at enable time and stores it in the OS keychain. Leave the key empty to run local-only.

Claude Code 2.1.258 loads both the user-scoped pascal server created by pascal mcp setup claude and the plugin-provided server. Remove the manual entry before reloading or restarting Claude Code so only the plugin owns the connection lifecycle:

claude mcp remove --scope user pascal

Use /mcp to remove or disable any project- or local-scoped Pascal connection too. Leaving both connections active violates the one-active-agent-client-per-local-service requirement. When the intended project is hosted in a Pascal account or organization, disable the plugin-provided local server in /mcp and configure the hosted endpoint from the skill setup guide instead.

Codex users can install the same plugin from the repository marketplace:

codex plugin marketplace add pascalorg/editor
codex plugin add pascal-agent-skills@pascal

OpenClaw installation becomes available after the skills are published under Pascal's ClawHub publisher. See skills/README.md for the owner-qualified install and verification commands.

pascal-3d covers safe local or hosted MCP setup and verified scene work. furniture-fit produces a bounded, evidence-based footprint assessment without claiming unsupported height, swing, or delivery checks. See skills/README.md for package details and validation.

The skills inspect the connected MCP tool schemas before using optional fields. A capability present in this repository may be absent from an older installed or hosted release; the agent should report the narrower supported result instead of assuming source-only inputs are available.

These workflows require a connected Pascal MCP server for their tool-backed actions. An OpenAI directory submission must therefore use With MCP and submit the production hosted MCP endpoint together with the skills. The repository package does not prove that the endpoint, OAuth flow, reviewer credentials, domain verification, or portal scan is ready for review.

MCP Registry

server.json is Pascal's manifest for the official MCP Registry. Its version tracks the hosted MCP implementation independently of the npm package version. Pull requests validate the manifest and production endpoint. A Pascal organization owner publishes an approved version from main with the official registry publisher.

Using Published Packages

The viewer runtime and built-in node definitions are separate packages. Install the full built-in viewer set, then load the built-in plugin once before mounting ``. Capture sessions are an optional extension shipped inside those packages as the @pascal-app/core/capture and @pascal-app/viewer/capture subpaths:

npm install @pascal-app/core @pascal-app/viewer @pascal-app/editor @pascal-app/nodes

import { loadPlugin } from '@pascal-app/core'
import { builtinPlugin } from '@pascal-app/nodes'
await loadPlugin(builtinPlugin)

See the @pascal-app/viewer quick start for a React example.

Repository Architecture

This is a Turborepo monorepo with the reusable editor packages, the standalone app, and the CLI that distributes it:

editor/
├── apps/
│   └── editor/          # Next.js application
├── packages/
│   ├── core/            # Schemas, scene state, registry contracts, capture contracts
│   ├── viewer/          # 3D rendering runtime, shared systems, capture runtime
│   ├── editor/          # Editing tools and UI components
│   ├── nodes/           # Built-in node definitions, renderers, and systems
│   ├── cli/             # Persistent local editor installer and process manager
│   ├── mcp/             # Model Context Protocol server and scene storage
│   └── ui/              # Shared UI components

Separation of Concerns

| Package | Responsibility | |---------|---------------| | @pascal-app/core | Node schemas, scene state (Zustand), registry contracts, spatial queries, and event bus. core/capture adds versioned capture manifests, normalized streams, and transport-neutral static/live sources | | @pascal-app/viewer | 3D rendering via React Three Fiber, shared render systems, default camera/controls, and post-processing. viewer/capture adds the capture runtime and reference model, device-motion, point-cloud, and surface-mesh layers | | @pascal-app/editor | Editing tools, panels, selection, and direct-manipulation UI | | @pascal-app/nodes | Built-in registry plugin with node definitions, renderers, geometry, and systems | | @pascal-app/cli | Installs and manages a versioned standalone editor runtime and persistent local data | | @pascal-app/mcp | Exposes scene tools, resources, prompts, and local storage to MCP-compatible AI hosts | | apps/editor | Standalone Next.js host for the editor packages |

The viewer renders the scene with sensible defaults. The editor extends it with interactive tools, selection management, and editing capabilities.

Stores

Each package has its own Zustand store for managing state:

| Store | Package | Responsibility | |-------|---------|----------------| | useScene | @pascal-app/core | Scene data: nodes, root IDs, dirty nodes, CRUD operations. Persisted to IndexedDB with undo/redo via Zundo. | | useViewer | @pascal-app/viewer | Viewer state: current selection (building/level/zone IDs), level display mode (stacked/exploded/solo), camera mode. | | useEditor | apps/editor | Editor state: active tool, structure layer visibility, panel states, editor-specific preferences. |

Access patterns:

// Subscribe to state changes (React component)
const nodes = useScene((state) => state.nodes)
const levelId = useViewer((state) => state.selection.levelId)
const activeTool = useEditor((state) => state.tool)
// Access state outside React (callbacks, systems)
const node = useScene.getState().nodes[id]
useViewer.getState().setSelection({ levelId: 'level_123' })

---

Core Concepts

Nodes

Nodes are the data primitives that describe the 3D scene. All nodes extend BaseNode:

BaseNode {
  id: string              // Auto-generated with type prefix (e.g., "wall_abc123")
  type: string            // Discriminator for type-safe handling
  parentId: string | null // Parent node reference
  visible: boolean
  camera?: Camera         // Optional saved camera position
  metadata?: JSON         // Arbitrary metadata (e.g., { isTransient: true })
}

Node Hierarchy:

Site
└── Building
    └── Level
        ├── Wall → Item (doors, windows)
        ├── Slab
        ├── Ceiling → Item (lights)
        ├── Roof
        ├── Zone
        ├── Scan (3D reference)
        └── Guide (2D reference)

Nodes are stored in a flat dictionary (Record), not a nested tree. Parent-child relationships are defined via parentId and children arrays.

---

Scene State (Zustand Store)

The scene is managed by a Zustand store in @pascal-app/core:

useScene.getState() = {
  nodes: Record,  // All nodes
  rootNodeIds: string[],       // Top-level nodes (sites)
  dirtyNodes: Set,     // Nodes pending system updates
createNode(node, parentId),
  updateNode(id, updates),
  deleteNode(id),
}

Middleware:

• Persist - Saves to IndexedDB (excludes transient nodes)
• Temporal (Zundo) - Undo/redo with 50-step history

---

Scene Registry

The registry maps node IDs to their Three.js objects for fast lookup:

sceneRegistry = {
  nodes: Map,    // ID → 3D object
  byType: {
    wall: Set,
    item: Set,
    zone: Set,
    // ...
  }
}

Renderers register their refs using the useRegistry hook:

const ref = useRef(null!)
useRegistry(node.id, 'wall', ref)

This allows systems to access 3D objects directly without traversing the scene graph.

---

Node Renderers

Renderers are React components that create Three.js objects for each node type:

SceneRenderer
└── NodeRenderer (dispatches by type)
    ├── BuildingRenderer
    ├── LevelRenderer
    ├── WallRenderer
    ├── SlabRenderer
    ├── ZoneRenderer
    ├── ItemRenderer
    └── ...

Pattern: 1. Renderer creates a placeholder mesh/group 2. Registers it with useRegistry 3. Systems update geometry based on node data

Example (simplified):

const WallRenderer = ({ node }) => {
  const ref = useRef(null!)
  useRegistry(node.id, 'wall', ref)

return (

        {/ Replaced by WallSystem /}

      {node.children.map(id => )}

  )
}

---

Systems

Systems are React components that run in the render loop (useFrame) to update geometry and transforms. They process dirty nodes marked by the store.

Core Systems (in @pascal-app/core):

| System | Responsibility | |--------|---------------| | WallSystem | Generates wall geometry with mitering and CSG cutouts for doors/windows | | SlabSystem | Generates floor geometry from polygons | | CeilingSystem | Generates ceiling geometry | | RoofSystem | Generates roof geometry | | ItemSystem | Positions items on walls, ceilings, or floors (slab elevation) |

Viewer Systems (in @pascal-app/viewer):

| System | Responsibility | |--------|---------------| | LevelSystem | Handles level visibility and vertical positioning (stacked/exploded/solo modes) | | ScanSystem | Controls 3D scan visibility | | GuideSystem | Controls guide image visibility |

Processing Pattern:

useFrame(() => {
  for (const id of dirtyNodes) {
    const obj = sceneRegistry.nodes.get(id)
    const node = useScene.getState().nodes[id]

// Update geometry, transforms, etc.
    updateGeometry(obj, node)
dirtyNodes.delete(id)
  }
})

---

Dirty Nodes

When a node changes, it's marked as dirty in useScene.getState().dirtyNodes. Systems check this set each frame and only recompute geometry for dirty nodes.

// Automatic: createNode, updateNode, deleteNode mark nodes dirty
useScene.getState().updateNode(wallId, { thickness: 0.2 })
// → wallId added to dirtyNodes
// → WallSystem regenerates geometry next frame
// → wallId removed from dirtyNodes

Manual marking:

useScene.getState().dirtyNodes.add(wallId)

---

Event Bus

Inter-component communication uses a typed event emitter (mitt):

// Node events
emitter.on('wall:click', (event) => { ... })
emitter.on('item:enter', (event) => { ... })
emitter.on('zone:context-menu', (event) => { ... })
// Grid events (background)
emitter.on('grid:click', (event) => { ... })
// Event payload
NodeEvent {
  node: AnyNode
  position: [x, y, z]
  localPosition: [x, y, z]
  normal?: [x, y, z]
  stopPropagation: () => void
}

---

Spatial Grid Manager

Handles collision detection and placement validation:

spatialGridManager.canPlaceOnFloor(levelId, position, dimensions, rotation)
spatialGridManager.canPlaceOnWall(wallId, t, height, dimensions)
spatialGridManager.getSlabElevationAt(levelId, x, z)

Used by item placement tools to validate positions and calculate slab elevations.

---

Editor Architecture

The editor extends the viewer with:

Tools

Tools are activated via the toolbar and handle user input for specific operations:

• SelectTool - Selection and manipulation
• WallTool - Draw walls
• ZoneTool - Create zones
• ItemTool - Place furniture/fixtures
• SlabTool - Create floor slabs

Selection Manager

The editor uses a custom selection manager with hierarchical navigation:

Site → Building → Level → Zone → Items

Each depth level has its own selection strategy for hover/click behavior.

Editor-Specific Systems

• ZoneSystem - Controls zone visibility based on level mode
• Custom camera controls with node focusing

---

Data Flow

User Action (click, drag)
       ↓
Tool Handler
       ↓
useScene.createNode() / updateNode()
       ↓
Node added/updated in store
Node marked dirty
       ↓
React re-renders NodeRenderer
useRegistry() registers 3D object
       ↓
System detects dirty node (useFrame)
Updates geometry via sceneRegistry
Clears dirty flag

---

Building a Plugin

The editor is extensible: a plugin ships node kinds (schema, 3D/2D rendering, placement tools, inspector parametrics) and left-rail panels through the same Plugin manifest the built-ins use — there is no separate internal API.

• Developer guide — Create a plugin: the Plugin shape, panel contributions, discovery, lifecycle, and what's in/out of v1.
• Worked example — pascalorg/plugin-trees: a standalone plugin with procedural trees, flowers, grass, and a presets panel. Clone it as a starting point.

---

Technology Stack

• React 19 + Next.js 16
• Three.js (WebGPU renderer)
• React Three Fiber + Drei
• Zustand (state management)
• Zod (schema validation)
• Zundo (undo/redo)
• three-bvh-csg (Boolean geometry operations)
• Turborepo (monorepo management)
• Bun (package manager)

---

Getting Started

Development

Run the development server from the root directory to enable hot reload for all packages:

# Install dependencies
bun install
Run development server (builds packages + starts editor with watch mode)
bun dev
This will:
1. Build @pascal-app/core and @pascal-app/viewer
2. Start watching both packages for changes
3. Start the Next.js editor dev server
Open http://localhost:3002

Important: Always run bun dev from the root directory to ensure the package watchers are running. This enables hot reload when you edit files in packages/core/src/ or packages/viewer/src/.

Building for Production

# Build all packages
turbo build
Build specific package
turbo build --filter=@pascal-app/core

Publishing Packages

Releases run from .github/workflows/release.yml (workflow_dispatch, with package, bump, and dry-run inputs). The workflow bumps versions, rewrites the internal @pascal-app/* ranges, builds, publishes in dependency order (core → viewer → editor → nodes → mcp → ifc-converter → cli), then commits the release and pushes one tag per package. A dry run validates the builds without touching the registry.

---

Key Files

| Path | Description | |------|-------------| | packages/core/src/schema/ | Node type definitions (Zod schemas) | | packages/core/src/store/use-scene.ts | Scene state store | | packages/core/src/hooks/scene-registry/ | 3D object registry | | packages/core/src/systems/ | Geometry generation systems | | packages/viewer/src/components/renderers/ | Node renderers | | packages/viewer/src/components/viewer/ | Main Viewer component | | apps/editor/components/tools/ | Editor tools | | apps/editor/store/ | Editor-specific state |

---

Contributing

Bug fixes, features, docs and ideas are all welcome. Start with CONTRIBUTING.md for setup, code style and the PR flow.

• New node kinds and sidebar panels ship as plugins rather than edits to the built-ins — pascalorg/plugin-trees is a worked example
• Questions and ideas go to Discussions; reproducible bugs go to Issues
• Participation is covered by our Code of Conduct
• Security problems go to SECURITY.md, not a public issue

---
